| Category | Parameter | Specification |
|---|---|---|
| General | Brand | Luminous |
| General | Product SKU / Model | LD6000-Pro |
| General | UPS Type | True Double-Conversion Online UPS |
| Capacity | Rated Capacity | 6000 VA / 5.4 kW |
| Electrical – Output | Output Phase | Single-Phase |
| Electrical – Output | Output Voltage | 230 V AC (configurable: 200 / 220 / 240 V) |
| Electrical – Output | Output Power Factor | ~0.9 |
| Electrical – Output | Output Waveform | Pure Sinewave |
| Electrical – Output | Current Crest Ratio | ~3:1 |
| Electrical – Input | Input Phase | Single-Phase |
| Electrical – Input | Input Voltage Range | 110 V – 300 V AC (wide range) |
| Electrical – Input | Input Frequency Range | 40 Hz – 60 Hz |
| Efficiency | Typical Efficiency | > 88 % |
| Battery | Battery Type | External SMF VRLA (user-supplied) |
| Battery | Battery DC Bus Voltage | 192 V DC |
| Battery | Maximum Charging Current | ~6 A |
| User Interface | Display | Multifunction LCD status & control panel |
| User Interface | Communication | Optional SNMP / communication cards |
| Acoustic | Noise Level | < 50 dB @ 1 m |
| Technology & Features | Control System | Microprocessor-based control |
| Technology & Features | Power Factor Correction | Input PFC supported |
| Technology & Features | Voltage Tolerance | Wide input voltage support |
| Technology & Features | Generator Compatibility | Yes |
| Technology & Features | Bypass | Automatic bypass |
| Physical | Dimensions (Approx.) | ~367 × 190 × 318 mm |
| Physical | Weight (Approx.) | ~12 kg |
Luminous LD6000-Pro Online UPS
The Luminous LD6000-Pro Online UPS (6 KVA / 5.4 kW) is a true double-conversion online UPS that delivers pure sinewave power with a high output power factor for critical single-phase loads. Designed with a wide input voltage range, microprocessor control, and robust efficiency, it supports external SMF/VRLA batteries (192 V) for extended backup runtime and is ideal for servers, networking equipment, and industrial electronics in environments with fluctuating mains power.
